Model Name HYP4850S100-H
Color White and BLACK
Operating Temperature Range -10-55℃
IP Grade IP20
Safety Class I
Max.Parallel 6
AC Output:
Rated Power 5000VA/5000W
Voltage 230Vac±5%
Rated Current 21.7A
Battery input:
Voltage Range 40~60Vdc
Rated Voltage 48Vdc
AC Input:
Voltage Range 170-280Vac
Frequency 50Hz/60Hz
Max.AC Bypass Current 40A
Max.AC Charge Current 60A
PV Input:
Max.Power 5500W
Max. Open Voltage 500V
MPPT Input Voltage Range 120-450Vdc
Max.Input Current 22A
PV Output:
Max.PowerMax, 5000W
Charge Current 100A
